The PM9600-HP910RBK10 represents the Datalogic PowerScan PM9600-HP full wireless industrial barcode scanner kit. This specific configuration operates on a 910 MHz radio frequency and features a High Performance (HP) dual-camera scan engine optimized for demanding trace-ability workflows.
Included Kit Components:
Scanner: PowerScan PM9600-HP Handheld Terminal (Yellow/Black)
Base Station: BC9630-910 Multi-Interface Cradle/Charger
Cable: CAB-552 IP67-rated straight USB Type-A interface cable (2m / 6.5 ft)
Power Infrastructure: 8-0935 power adapter brick and 6003-0941 US regional line cord
Product Capabilities:
High Performance Dual-Camera Optics: The "HP" scan engine utilizes a dual-camera system rather than a single sensor. This configuration provides a wider depth of field and 20% faster read rates, capturing low-density or complex 1D and 2D codes across a generous scan distance of up to 95.6 inches (2.42 meters).
STAR Cordless System (910 MHz): Operates on Datalogic’s proprietary narrowband radio frequency instead of standard Bluetooth. This completely eliminates Wi-Fi interference and secures reliable bi-directional communication over ranges exceeding 100 meters (328 feet).
Contactless Inductive Charging: Utilizes a contactless wireless charging system built into the cradle. By eliminating exposed metal battery contacts and spring pins that frequently collect grime or break, this design removes a primary point of device hardware failure.
Ultra-Rugged Industrial Durability: Engineered to survive tough factory floor conditions, the housing carries dual IP65 and IP67 dust and moisture sealing ratings. It is certified to withstand up to 50 drops from 8.2 feet (2.5 meters) onto solid concrete.
Advanced Operator Feedback: Combines a loud audible beeper, a vibration motor, and Datalogic's patented 3GL (Three Green Lights) system—including a projected green spot directly onto the scanned barcode—for definitive verification in noisy warehouse environments.
Product Specifications:
Scan Engine Resolution: 1280 x 800 pixels (Area Imager)Supported Codes: 1D, 2D (Data Matrix, QR, Aztec), Postal, Stacked, and Digimarc digital watermarks
Battery Power: 3350 mAh removable Lithium-Ion battery
Recharge Time: 3.2 hours to full charge
Illumination: Gentle white LED light with an instinctive target framing aimer
Physical Dimensions: 7.8" Height x 3.1" Width x 5.5" Length
