Startech

StarTech 2U Universal Vented Rack Shelf – 16" Deep - 50lb Capacity - CABSHELFV

SKU:
STARTECH CABSHELFV NEW
UPC:
065030848084
MPN:
CABSHELFV
Condition:
New
Availability:
Should Ship in 1-3 Business Days.
Shipping:
Calculated at Checkout
  • A rear-angled perspective view of a StarTech 2U Universal Vented Rack Shelf (CABSHELFV), showcasing the back and side profiles of the unit. The image illustrates the following: Rear Lip: A vertical metal flange at the back of the shelf acts as a backstop to prevent equipment from sliding off. Vented Surface: Two distinct grids of elongated ventilation slots are visible across the flat tray, designed to facilitate passive cooling for mounted hardware. Mounting Brackets: The integrated side brackets extend toward the front, featuring pre-drilled holes for standard 2U rack mounting. Material: The shelf is constructed from sturdy, matte black cold-rolled steel. The component is shown against a plain white background, highlighting its clean lines and industrial design.
  • An angled perspective view of a StarTech 2U Universal Vented Rack Shelf (CABSHELFV) designed for standard 19-inch server racks. The image highlights the following structural features: Construction: A heavy-duty, cold-rolled steel shelf with a matte black powder-coated finish. Vented Design: The flat surface of the shelf features two large sections of horizontal ventilation slots to promote airflow and prevent equipment from overheating. Mounting Brackets: The shelf has integrated 2U height side brackets with pre-drilled mounting holes at the front for secure attachment to a server rack or cabinet. Form Factor: A cantilever (front-mount) design with a solid lip at the back to help keep non-rackmount equipment, such as routers or small switches, in place. The shelf is shown against a plain white background, emphasizing its industrial build quality and functional design.
  • An infographic detailing the physical features and technical specifications of the StarTech 2U Universal Vented Rack Shelf (CABSHELFV). Top Section: Product Dimensions A 3D perspective view of the black metal shelf includes several labeled dimension lines: Height: 3.5 inches (9 cm). Depth: 16 inches (41 cm). Total Product Width: 19 inches (48 cm). Usable Product Width: 17 inches (44 cm). The image clearly shows the vented tray surface and the integrated mounting brackets at the front.
  • An infographic illustrating the cooling capabilities of the StarTech 2U Universal Vented Rack Shelf (CABSHELFV). The image features the following elements: Heading: Large black text at the top reads, "Maximize Airflow and Heat Dissipation with Built-In Vents." Below this, a smaller sub-headline states, "Promotes passive cooling to keep your equipment at safe operational temperatures." Product Illustration: A front-facing perspective view of the matte black steel shelf. Four large, stylized blue arrows point through the horizontal ventilation slots on the shelf's surface—two pointing downward through the rear vents and two pointing forward through the front vents—to visually represent airflow. Design Details: The shelf is shown with its integrated 2U mounting brackets and a solid center tray area between the two vented sections. The infographic is set against a clean white background, focusing on the functional benefit of the vented design for server rack environments.
  • An infographic showcasing the StarTech 2U Universal Vented Rack Shelf (CABSHELFV) installed in a server rack, highlighting its use in professional environments. Top Section: Marketing Graphics The top half features blue text on a white background that reads, "Install in Your Vented Rack to Optimize Your Equipment Storage." Below this are four blue icons representing recommended use cases: Server Rooms: Three stacked server units. Data Centers: Multiple server racks. Offices: A high-rise building. Warehouses: A shopping cart icon. Bottom Section: Product in Use The bottom half shows a close-up photo of the black vented shelf mounted inside a standard server rack. Equipment: A network switch is sitting on the shelf. Five blue Ethernet cables are plugged into the switch and routed upward to a 24-port patch panel mounted directly above it. Rack Context: Above the patch panel, a large grey server unit is visible. Ventilation: The slotted design of the shelf is clearly visible, showing how it supports non-rackmount equipment while allowing for airflow between the components.
  • A technical infographic showing the engineering drawings and precise dimensions for the StarTech 2U Universal Vented Rack Shelf (CABSHELFV). The image contains three distinct schematic views labeled in black text: Top View A plan view showing the layout of the ventilation slots across the shelf surface. Width: 17.4 inches (443 mm). Front View A schematic of the shelf's face, showing the mounting brackets and tray profile. Total Width (including brackets): 19 inches (483 mm). Tray Width: 18.3 inches (465 mm). Mounting Hole Spacing: 1.3 inches (32 mm). Side View A profile view highlighting the shelf's depth and the height of the rear lip. Total Depth: 16 inches (406 mm). Total Height: 3.5 inches (88 mm). Front Bracket Depth: 3.2 inches (80 mm). Rear Lip Height: 1.9 inches (48 mm). The infographic is presented as a clean black-and-white line drawing on a white background, with the title "Technical Drawing and Dimensions" at the top.
$49.99
Current Stock: 15

Sold Out

Frequently bought together:

Description

The StarTech.com CABSHELFV 2U 16in Universal Vented Rack Mount Cantilever Shelf is a durable, high-quality fixed shelf designed to house non-rackmountable equipment, IT peripherals, tools, and A/V components within a standard 19-inch server rack or cabinet. This heavy-duty shelf is constructed from SPCC commercial-grade cold-rolled steel, offering a 50 lb (22.7 kg) weight capacity. Its vented design promotes increased airflow to prevent equipment from overheating, making it ideal for data centers, server rooms, and office environments.

Product Features:

Universal Compatibility: Designed to fit virtually any standard 19-inch 2-post or 4-post server rack or cabinet.
Vented Design: The perforated surface maximizes airflow, assisting in lower operating temperatures for your equipment.
Robust Construction: Built with 1.6mm thick SPCC cold-rolled steel, providing a sturdy, reliable storage solution.
2U Capacity: Efficiently utilizes 2U of rack space with a 16-inch depth.
TAA Compliant: Adheres to the Federal Trade Agreements Act (TAA), making it eligible for GSA Schedule purchases.
Lifetime Warranty: Backed by a StarTech.com lifetime warranty and free technical support.

Technical Specifications:

Product Type: Cantilever Shelf (Fixed)
Rack Height: 2U
Depth: 16 inches (406mm)
Weight Capacity: 50 lb / 22.7 kg
Color: Black
Material: Steel (SPCC)
Mounting Type: Front mount only (2-post compatible)
Included Hardware: 4x M5 screws, 4x M5 cage nuts
