NavePoint

NavePoint 12U Wallmount Open Frame Rack Threaded - 00404151

SKU:
NAVEPOINT 00404151 NEW
UPC:
813770022802
MPN:
00404151
Condition:
New
Availability:
Should Ship in 1-3 Business Days.
Shipping:
Calculated at Checkout
  • A three-quarter perspective shot of a black, metal 12U wall-mount open-frame server rack against a white background. The image shows the rack's depth and structural design, featuring vertical mounting rails at the front with threaded holes and white U-space markings. The side and rear panels include multiple keyhole cutouts for wall mounting and vertical slots for cable management. The open-frame construction allows for maximum airflow and easy access to hardware from all angles.
  • An infographic showcasing the features of a black, metal 12U wall-mount open-frame server rack. The central image shows a front-facing view of the rack, with four dashed lines leading to circular close-up callouts that highlight specific design elements: Bolted Assembly: Shows a top corner joint secured with hardware. Fits Standard 19” IT Equipment: Displays the top of a mounting rail, confirming compatibility with standard rack-mount gear. Easy Cable Management: Highlights the open-frame base and side rails that allow for versatile cable routing. Threaded Mounting Holes: Close-up of the vertical rail showing pre-threaded holes and a keyhole cutout for wall mounting. The top of the image features a green and black banner with the text "FEATURES 12U WALL MOUNT RACK."
  • An infographic detailing the specifications for a black, metal NavePoint 12U wall-mount open-frame rack. A three-quarter perspective image of the rack is positioned on the right with green dimension arrows indicating its size: Height: 24.15" Width: 20" Depth: 15.8" On the left, four green icons with bold text list the following specifications: Powder coated: Finish Cold rolled steel: Material Wall-mounted: Rack 110 lbs: Weight capacity The top of the image features a green and black header with the text "SPECIFICATIONS 12U WALL MOUNT RACK" and the NavePoint logo in the upper-right corner.
  • A front-facing, slightly angled shot from above, showcasing a black, metal 12U open-frame server rack shelf. Three parallel rows of multiple vertical ventilation slots run across the width of the shelf, which sits horizontally against a white background. Small flanges are visible on the far-left and far-right edges, designed for mounting into a server rack. The perspective shows the top surface of the shelf.
  • A front-facing, straight-on shot of a black, metal 12U wall-mount open-frame server rack against a white background. The rack features a rectangular frame with two vertical mounting rails on the left and right, each containing threaded mounting holes and white U-space markings for organized equipment installation. The interior side panels include keyhole-shaped cutouts for mounting the rack to a wall. The open-frame design provides easy access to equipment from all sides.
  • A front-facing, straight-on shot of a black, metal 12U wall-mount open-frame server rack against a white background. The rack consists of a rectangular frame with two vertical side rails featuring threaded mounting holes for hardware installation. Each side panel includes two keyhole-shaped cutouts for wall-mounting. The open-frame design provides clear visibility through the center and easy access to equipment from the front, back, and sides.
  • A close-up, high-angle shot of the top corner of a black, metal open-frame server rack on a white background. The image highlights the assembly where two horizontal support beams meet a vertical mounting rail, secured by a single black screw. The vertical rail features threaded mounting holes and white U-space markings to guide equipment installation. A keyhole cutout for wall mounting is partially visible on the interior side of the frame.
$194.99
Current Stock: 14

Sold Out

Frequently bought together:

Description

The NavePoint 12U Wallmount Open Frame Rack (Model 00404151) is a heavy-duty, space-saving solution designed to organize and secure standard 19-inch IT and A/V equipment. Its open-frame design is optimized for environments like network closets or back offices where maximum airflow and easy equipment access are critical.

Product Features & Build:

Heavy-Duty Construction: Built from 1.5mm high-quality SPCC Cold Rolled Steel with a durable black powder-coated finish.
Threaded Mounting: Features 12-24 threaded mounting holes on one side and can be used for 2-post mounting of servers, switches, and patch panels.
High Load Capacity: Engineered with double-reinforced wall-anchor mounting holes to support up to 110 lbs.
Passive Cooling: The open sides and front allow for unrestricted airflow, preventing hardware from overheating during intensive operations.
Cable Management: Includes rear slots for cable ties and pre-drilled holes for cable management rings to keep your setup tidy.

Technical Specifications:

Rack Units: 12U
External Dimensions: 24.15" H x 20" W x 15.8" D
Max Mounting Depth: 15.6 inches
Weight Capacity: 110 lbs
Compatibility: Standard 19-inch rack equipment
Compliance: CE, DIN 41494, EIA/ECA-310-E

View AllClose

Warranty Information

30-Day Limited Warranty – New Products : Your new item is covered for 30 days from the purchase date against defects in materials or workmanship. If your product is defective, we will repair or replace it at no charge. This warranty does not cover damage from accidents, misuse, cosmetic wear, or unauthorized repairs. To make a claim, contact us at ecommerce@posrg.com with proof of purchase.
