Elo Edge Connect 2D Barcode Scanner - E926356

The Elo 2D Barcode Scanner (P/N: E926356) is a commercial-grade, modular scan engine designed to seamlessly integrate with Elo’s interactive touchscreen ecosystems. Powered by the robust Honeywell N3680 scan engine, this low-profile peripheral easily attaches to the edges of compatible Elo monitors and all-in-one terminals.

It allows businesses to quickly deploy self-service, price-checking, hospitality, and endless-aisle kiosk solutions without messy external cabling.

Product Features:

Seamless Edge Connect™ Integration: This scanner mounts directly to the micro-USB peripheral bays built into the sides of select Elo touchscreens. It secures tightly with two mounting screws, achieving an integrated, tamper-resistant, and unified hardware appearance.
High-Performance 2D Scans: The CMOS-based sensor reads standard 1D linear codes, high-density 2D barcodes (such as QR codes and Data Matrix), and digital barcodes straight off customer smartphone screens.
Intelligent Aiming & Feedback: Built with bright white LED illumination and an intuitive red LED dot aimer for accurate targeting. A loud, integrated 85 dB internal beeper gives instant audible confirmation in noisy retail or warehouse settings.
Out-of-the-Box Configuration: Ships pre-configured in Virtual COM Port (VCP) mode with Presentation Mode enabled. This allows for continuous, hands-free scanning as items pass the field of view.

Product Specifications:

Manufacturer Part Number: E926356 (Model: 2DBCR)
Scan Engine: Honeywell N3680 Series Decoded 2D Engine
Sensor & Resolution: CMOS Sensor | 640 x 480 pixels
Host Interface: Micro-USB (Plug-in Card form factor)
Ideal Scan Range: 60mm to 152mm (2.3" to 6.0") depending on barcode density
Field of View: 37.8° Horizontal x 28.8° Vertical
Supported Terminal Modes: HID Keyboard Emulation, USB Serial / VCP
Operating Current: 220 mA Active Scanning | 65 mA Idle | 2.5 mA Standby
Dimensions: 4.68" x 1.15" x 0.63" (118.9mm x 29.1mm x 16.0mm)
Weight: 0.06 lbs ( unpackaged ) | 0.36 lbs ( packaged )
